Network SimpleRouteError

Package: nesg.netattacks.simulations.SimpleAttackScenarios.SimpleRouteErrorScenario
File: simulations/SimpleAttackScenarios/SimpleRouteErrorScenario/SimpleRouteError.ned

(no description)

NA_AdhocHost FlatNetworkConfigurator ChannelControl

Usage diagram:

The following diagram shows usage relationships between types. Unresolved types are missing from the diagram.

Inheritance diagram:

The following diagram shows inheritance relationships for this type. Unresolved types are missing from the diagram.

Parameters:

Name Type Default value Description
numHosts int

Properties:

Name Value Description
isNetwork
display bgb=700,300,grey75

Unassigned submodule parameters:

Name Type Default value Description
node.networkLayer.ip.procDelay double 0s
node.networkLayer.ip.timeToLive int 32
node.networkLayer.ip.multicastTimeToLive int 32
node.networkLayer.ip.fragmentTimeout double 60s
node.networkLayer.ip.forceBroadcast bool false
node.networkLayer.arp.retryTimeout double 1s

number seconds ARP waits between retries to resolve an IPv4 address
node.networkLayer.arp.retryCount int 3

number of times ARP will attempt to resolve an IPv4 address
node.networkLayer.arp.cacheTimeout double 120s

number seconds unused entries in the cache will time out
node.networkLayer.arp.globalARP bool false
node.routingTable.routerId string "auto"

for routers, the router id using IPv4 address dotted notation; specify "auto" to select the highest interface address; should be left empty ("") for hosts
node.routingTable.forwardMulticast bool false

turns multicast forwarding on/off
node.interfaceTable.displayAddresses bool true

whether to display IP addresses on links
node.pcapRecorder.verbose bool false

whether to log packets on the module output
node.pcapRecorder.pcapFile string ""

the PCAP file to be written
node.pcapRecorder.snaplen int 65535

maximum number of bytes to record per packet
node.pcapRecorder.dumpBadFrames bool true

enable dump of frames with hasBitError
node.pcapRecorder.moduleNamePatterns string "wlan[*] eth[*] ppp[*] ext[*]"

space-separated list of sibling module names to listen on
node.pcapRecorder.sendingSignalNames string "packetSentToLower"

space-separated list of outbound packet signals to subscribe to
node.pcapRecorder.receivingSignalNames string "packetReceivedFromLower"

space-separated list of inbound packet signals to subscribe to
flatNetworkConfigurator.networkAddress string "192.168.0.0"

network part of the address (see netmask parameter)
flatNetworkConfigurator.netmask string "255.255.0.0"

host part of addresses are autoconfigured
channelControl.coreDebug bool false

debug switch for core framework
channelControl.pMax double 20mW

maximum sending power used for this network (in mW)
channelControl.sat double -110dBm

signal attenuation threshold (in dBm)
channelControl.alpha double 2

path loss coefficient
channelControl.carrierFrequency double 2.4GHz

base carrier frequency of all the channels (in Hz)
channelControl.numChannels int 1

number of radio channels (frequencies)
channelControl.propagationModel string "FreeSpaceModel"

Source code:

network SimpleRouteError
{
    parameters:
        int numHosts;
        @display("bgb=700,300,grey75");
    submodules:
        node[numHosts]: NA_AdhocHost {
            @display("p=100,50");
        }
        flatNetworkConfigurator: FlatNetworkConfigurator {
            @display("p=100,250");
        }
        channelControl: ChannelControl {
            @display("p=250,250;i=misc/sun");
        }
    //connections allowunconnected:
}
